Sliding Fitting

Inline XL

InLine XL is the first sliding door system to do away with handles completely. For the last word in design flexibility.
InLine XL lets you create flush fitted units that provide premium class convenience: the handleless front opens in response to a light pull on the door's leading edge. Unbridled flexibility in the use of handles too – you can position them wherever you prefer. Exquisitely smooth running action. Silent System adjusts to suit any preference. Flush opening doors. And design that's overwhelming too: no offset to spoil the look, no visible gaps. Sliding can be as attractive as this.
• Top running sliding door system
• Flush fitted doors
• For wooden or aluminium framed doors
• Doors weighing up to 60 kg
• Door height up to 2600 mm
• Door width 750 - 2000 mm
• Door thickness 16 – 25 mm
• Height adjustment, adjustable door overlay and tilt
• Silent System (adjustable) in opening and closing direction
