SlideLine M upgrades the practical value and design of furniture. Living room units and shelf systems. Kitchen wall units and bathroom furniture. And, of course, office cabinets too. The versatile system is suitable for all common furniture constructions.
Wooden, glass or aluminium framed doors weighing up to 30 kg can be installed quickly and easily. Profiles are available for several shelf thicknesses. Sliding doors running one in front of the other in one profile are also easy to produce.
The Silent System is integrated on the running component and slows down door running action in closing, opening and colliding direction.
Including a feel of luxury: Silent System lets doors open and close quietly and gently. Where several doors run side by side in one profile, they can even be slowed down as they move towards each other.
• 1-track, bottom running sliding door system
• Overlay door position
• Wooden, glass or aluminium framed doors
• Door weight up to 30 kg
• Door height up to 2000 mm
• Door width from 300 - 1800 mm
• Shelf thicknesses 15, 16, 18, 19, 22, 25 mm
• Height adjustment +/- 2 mm
• Silent System in closing, opening and colliding direction
• Tool-less fast installation of the front panel
• Tested to EN 15706, Level 1 or 3
